With the ever-evolving world of electronic manufacturing, Ball Grid Array (BGA) assembly has been a key technology. This advanced IC packaging process is meeting the demand for denser, high-performance devices with accuracy, efficiency, and reliability. As electronic designs become more complex and pack more functionality in less space, the use of BGA assembly becomes increasingly vital.


Ball Grid Array (BGA) is an integrated circuit surface-mount packaging technology, a new generation of packaging technology that uses an array of solder balls on the lower surface of a package to connect electrically with a printed circuit board (PCB). Unlike traditional packaging technologies such as Dual In-line Package (DIP) or Quad Flat Package (QFP) that use pins or wires, BGA uses a higher pin density, which is required by modern high-performance electronics.


BGA Assembly Capability | PCBCart


BGA Assembly Steps


BGA assembly on printed circuit boards (PCBs) is a process of carrying out several precise and controlled steps to reach optimum performance and reliability. Below are the most prominent stages that are typically followed by the process of BGA assembly:


PCB Preparation: It begins with PCB preparation, in which the solder paste is deposited onto the pads onto which the BGA components will be soldered. Solder paste is an alloy of the solder particles and flux, making the soldering process easier through proper wetting and joining in reflow.


BGA Placement: The BGAs, with the chips of the integrated circuits and the solder balls at their bottom sides, are then positioned over the prepared PCB. Placement in the majority of cases is performed using automated pick-and-place machines that allow precise positioning and alignment necessary for proper assembly.


Cooling and Inspection: Subsequent to the reflowing process, the PCB cools down as a result of which the liquid solder turns to solid and forms high-strength solder joints. A process of inspection is undertaken where the possible defects such as misalignments, shorts, or open contacts in the assembly are detected and addressed. High-level techniques like Automated Optical Inspection (AOI) or X-ray inspection are predominantly utilized in order to obtain entire quality assurance.


Final Processes: Depending on specific product requirements, other processes could be performed after the main assembly. These can include cleaning the assembly for removing any residues, performing a number of functional tests to validate the performance, and the use of conformal coatings for increased protection and durability, to maintain the overall quality and reliability of the finished product.


Advantages of BGA Assembly


BGA assembly is favorable to many advantages that make it a necessity in electronic device design development:


Dense and Compact Design: BGA packages provide a high level of connectivity in a comparatively small size, enabling one to integrate increased functionality into small designs. This is especially beneficial in today's electronics, where space is precious.


Enhanced Electrical and Thermal Performance: The shorter lead length in BGA packages enhances electrical performance by reducing inductance and capacitance. The packaging also has better heat dissipation, which is a critical factor in maintaining the device reliable under high operating temperatures.


Robustness and Reliability: BGA packages sacrifice traditional pins to bending or fracture in lieu of an array of solder balls. This allows for improved mechanical robustness, leading to added durability and production yields.


Less Parasitic Effects: BGA packaging is less parasitic in inductance and capacitance due to its high-density and efficient nature. This leads to improved signal integrity and performance, particularly for high-speed devices.


Stable Signal Transmission: The linear extension of signals from the center of the chip, typical of BGA packaging, reduces signal transmission paths, which in turn minimizes signal attenuation and increases response speeds. This stability is critical for demanding applications requiring precise signal integrity.

Advantages of BGA Assembly | PCBCart


Innovations Driving BGA Assembly Forward


The need for high-performance, compact electronics has spurred BGA assembly process innovation:


Advanced Inspection Systems: Automated inspection machines, including sophisticated X-ray and AOI equipment, have revolutionized quality control in BGA assembly, allowing extensive and non-destructive inspection.


Advanced Solder Materials: Novel solder pastes with increased adhesion and reduced void formation have improved the quality and reliability of the solder joints in BGA assemblies.


Robotics and Automation: Integration of robotics and automated systems within the assembly process has significantly increased accuracy and speed, reducing human error and increasing production efficiency.


PCBCart: BGA Assembly Leaders


PCBCart is a leader in the PCB industry, offering high-quality BGA assembly services that are characterized by quality, precision, and innovation. With years of experience and advanced technology, PCBCart is well-equipped to deal with diverse customers with unmatched reliability.


Advanced Equipment and Techniques in PCBCart


Our advanced facilities in PCBCart boast fully-automated SMT production lines with the most up-to-date technology, including automated solder dispensers, precision pick-and-place machines, reflow ovens, and detailed inspection systems. This enables us to attain high precision and yield in our BGA assembly processes.


Complete Inspection and Capabilities


Understanding the intricacies involved with testing BGA assemblies, PCBCart uses a mix of electrical testing, boundary scanning, and X-ray inspection technologies to thoroughly check solder joint integrity. Our services cover various types of BGA as below:


Types of BGA Assembly

Plastic Laminate BGA ((PBGA))

Tape Ball Grid Array (TBGA)

Ceramic Ball Grid Array (CBGA)

Flip Chip Ball Grid Array (FCBGA)

Enhanced Ball Grid Array (EBGA)

Micro BGA

Package on Package (PoP)

Chip Scale Package (CSP)

Wafer level chip scale packaging


Our experience enables us to accommodate the specific needs of industries like medical devices, telecommunications, automotive, and industries. By providing tailored BGA assembly services, we are able to have each project leverage our commitment to quality and innovation.

Optimize BGA Assembly Solutionswith PCBCart


Ball Grid Array assembly is an important technology innovation in PCB manufacturing addressing the demands of modern electronic devices, with miniaturization as the utmost concern without any loss of performance. Relying on its professional approach and state-of-the-art solutions, PCBCart has all it takes to deliver superior BGA assembly services.


With evolving electronics production, PCBCart continues to be at the forefront with unparalleled experience and service in BGA assembly. Excellence is our commitment, and each project is not only up to but also beyond industry standards. Leave your BGA assembly needs PCBCart and experience the future of electronics production today, where precision, reliability, and customer satisfaction are our guiding principles.
